With its extended buss structure, the PowerMate-3 offers very flexible configuration options. In all, 6 AUX busses are available:
2 (FX) are assiged to the two effects sends
2 (AUX) can be configured either as monitor or effects sends by means of a switch in the Main section
2 (MON) are designed as monitor sends, each being equipped with a sweepable anti-feedback filter in the Master section.
Offers a wide range of functionality in a very compact frame
Ergonomic console shape and clearly structured controls provide perfect overview for instant access at all times
Through its multiple functions, its high dynamic capacity and extremely low-noise design in combination with its 24-bit Dual-Stereo effect unit
Contents:1 x PowerMate
Main Feature: 24 Channel console
Inputs: 18 x Microphone XLR/Line Jack, 4 x Microphone XLR/Stereo line jacks
Inserts: For mono channels
EQ Mono / Stereo channel: 3 band; semi parametric mids / 3 band fix
AUX send/stereo return: 2 x pre 2 x pre/post, 2 x post
Channel volume control: 60mm fader
Outputs: Main-mix-out/balanced.: XLR & jack
Effects: Digital Effects processor
External Dimensions ( Width x Depth x Height ): 155 x 818,5 x 498,5 mm
